Mineral Wool Acoustic Panel — product photograph

Acoustic Panel

Mineral Wool Acoustic Panel

SKU: ACO-033B70 SGS tested CE marked ISO 9001
Request a Quote Request a Sample Download Spec Sheet

Specification

Specification for Mineral Wool Acoustic Panel
Core Mineral wool — non-combustible, and the reason this panel is specified where a class is named
Absorption The mineral core reaches a given figure in less depth than a felt panel does
Thickness 9 / 12 / 15 / 18 / 20 / 25 mm; the depth needed follows from the target, not from preference
Format 1220 × 2440 mm sheet, or factory-cut 600 × 600 and 600 × 1200 tiles
Mounting Air gap behind the panel — the cavity is part of the absorber, not a fixing detail
Facing An acoustically transparent facing lets the core work; a sealed veneer reflects sound
Standard ASTM C423 for sound absorption. Ask for the report for the grade you specify.

What this product does

  1. 1
    Non-combustible core

    Mineral wool, which is why it is named where a fire class is specified

  2. 2
    More absorption per depth

    Reaches a given figure in less thickness than a felt panel

  3. 3
    Facing is part of the spec

    A sealed veneer reflects sound, so the facing changes the performance

  4. 4
    Cutting makes dust

    Cut outside the room or behind a seal in an occupied building

Description

An acoustic panel with a mineral wool core and a fabric or veneer facing. Two properties separate it from a felt panel: the core is non-combustible, and it absorbs more sound per unit of thickness.

Those are the reasons it is specified where a fire class is named, or where a room needs a high absorption figure without surrendering much depth — halls, auditoria, music rooms, large offices. It mounts direct or on battens with a concealed fixing, and it needs the same air gap behind it as any absorber: the cavity is part of the performance, not a fixing detail. The practical caution is dust. The finished panel does not shed, but cutting mineral wool on site does, so in an occupied building the cutting has to happen outside the room or behind a seal — that is the one real operational difference from a polyester panel. The other detail is the facing: an acoustically transparent facing lets the core work, while a sealed decorative veneer reflects sound and quietly cancels the absorption you paid for. If a veneer is wanted, confirm the facing before the order rather than after.

Send the room type, the target absorption and any fire class when you enquire, and tell us if the environment is humid so the facing and edges can be matched to it.

Where it is used

Auditoria and halls

A high absorption figure in limited depth, with a class to meet

Music practice rooms

The room where the class and the figure are both written into the spec

Cinema and media rooms

Deep absorption on the walls with a fire requirement on top

Large open-plan floors

Absorption spread across a big plate, where depth per panel matters

See all application guides

Frequently asked

What is the minimum order?

1 × 20ft container, mixed across products where the mix suits the project. A sample box can be arranged before the first container.

Can I see a sample before ordering?

Yes. Send the product and the size you are specifying, and we will confirm the sample and the lead time for it.

Why choose mineral wool rather than a felt panel?

Two reasons: it is non-combustible, and it absorbs more per unit of thickness. Where the specification names a fire class, or where the room needs a high absorption figure in a limited depth, mineral wool is the core that gets there.

Does mineral wool shed dust?

The factory-finished panel does not, but cutting it on site does. If the work is in an occupied building, cut outside the room or seal the area — that is the practical difference from a PET panel.

Is the facing breathable?

The acoustically transparent facings are; a sealed decorative veneer is not, and a sealed face reduces absorption. If you are specifying a veneer, tell us and we will confirm the facing that keeps the performance.

Can it be used in a humid room?

Only with the right facing and edge detail. Standard mineral wool is not for a pool hall; tell us the environment before choosing the panel.

Trade terms

MOQ
1 × 20ft container
Lead time
15-25 days
Payment terms
T/T 30% deposit, balance before shipment

Final packing, freight and loading plan are confirmed in writing on the order quotation.
