H20 Timber Beam Supplier | China

Solid timber and steel-form H20 beams to EN 13377. Section governs the load, not length.

Narrow it down

H20-E3631D Get a Quote

Section 200 × 80 mm nominal H20 envelope, with steel edge protection
Edge Steel caps take the stripping damage that starts a split in a plain timber beam

H20-4189D9 Get a Quote

Parameter	Values
Section	200 × 80 mm nominal H20 profile per EN 13377 · 200 × 80 mm nominal H20 envelope, with steel edge protection
Type	Solid timber beam, planed and end-sealed — no steel edge
End sealing	End grain takes up water fastest, and water in the end grain starts a split along the length
Load case	The section governs the load, not the length — confirm the section against the drawing
Use	Formwork support: wall and slab systems, deck joists, soldier and waler runs · Repeat-use formwork where beams are stripped and re-set many times
Standard	EN 13377, prefabricated timber formwork beams
Length	Cut to the pour sequence; standard lengths confirmed at quotation
Edge	Steel caps take the stripping damage that starts a split in a plain timber beam
Limit	The steel protects the edge; it does not add capacity — the load case is still the drawing
Web	Timber web behind the steel edge, so the beam stays light enough to set by hand

Tolerances and densities vary by section profile. Send the drawing for the exact values on your order.

Tell us the profile, the length and the quantity. We will confirm what is in stock and what is made to order.
